Safety guard system prevents activation of the cutter when foreign objects are present (fingers, tools, etc.)
Auto feed & cut
For middle to high duty work
Compact design with plastic cabinet
Length settable by 1mm inteval with LED
Dispense 30mm to 999mm in tape length
Acceptable Tape width from 7mm to 50mm
Tolerance ±3mm (Depend on type of material)
Various packaging and industrial tapes applicable.
Photocell actuated feed & cut or push-button feed & cut LED Digital length adjustment
Specification
Tape Width
7-50mm (0.28 to 2")
Cut Length
30-999mm
Feed
Automatic
Cut
Automatic
Cutting Edge
Straight
Recommend for
Med-high Duty Production
Length Memory
N/A
Max tape dia.
170mm
Applicable tapes
Filament, Paper craft, Cloth, Double sided, Cellophane, OPP, Vinyl, Masking, etc.
Operatable environment
"5℃-40℃,Under RH80%"
Power(Main Unit):
DC18V 1A(use dedicated AC adaptor)
Size(W×L×H)
137×249×156mm
Weight
2,300g
Enclosed
AC adaptor, Triple reel unit, Silicone oil and Quick manual label
